UPS Vertiv GXT RT 1ph 3kVA IEC60320 C20 2U output 230V (6)C13 (1)C19 GXTRT-3000IRT2UXL

Marca: Vertiv
SKU: GXTRT-3000IRT2UXL

Descripción Vertiv SAI GXTRT-3000IRT2UXL 2700V
EU PLUG.
Specifications:
Features:
- UPS topology:
Double-conversion (Online).
- Output power capacity:
3 kVA.
- Output power:
2700 W.
- Waveform:
Pure sine.
- Input operation voltage (min):
179 V.
- Input operation voltage (max):
288 V.
- Input frequency:
40.
- 70 Hz.
- Output operation voltage (max):
240 V.
- Output frequency:
50/60 Hz.
- Output voltage regulation:
1%.
- Number of input phases:
1.
- Number of output phases:
1.
- Efficiency:
90%.
- Efficiency (On-line mode):
90%.
- Power factor:
0.9.
- Input power factor:
0.9.
- Output power factor:
0.9.
- Emergency Power Off (EPO):
No.
- Noise leve:
l55 dB.
- Power protection Features:
Overload.
- Audible alarm(s):
Yes Ports & interfaces:
- AC outlet types:
C13 coupler, C19 coupler.
- Power plug:
C14 coupler.
- AC outlets quantity:
7 AC outlet(s).
- USB port:
Yes.
- Serial ports quantity:
1 Battery:
- Battery technology:
Sealed Lead Acid (VRLA).
- Battery capacity:
9 Ah.
- Battery voltage:
12 V Battery:
- Number of batteries supported:
6.
- Typical backup time at full load:
3.3 min.
- Typical backup time at half load1:
1 min.
- Hot-swap battery:
Yes Design:
- Form factor:
Rackmount.
- Rack capacity:
2U.
- Display:
LCD.
- Safety:
CE.
- Certification:
CE Mark.
IEC/EN 62040-1:
2014, IEC/EN 62040-2:2006+AC:2006 Class A, EN 61000-4-5:
2005 Class 2 L-N, Class 3 L-G, ISTA 2A Operational conditions:
- Operating temperature (T-T):
0.
- 40 °C.
- Storage temperature (T-T):
-20.
- 50 °C.
- Operating relative humidity (H-H):
20.
- 95%.
- Storage relative humidity (H-H):
10.
- 90%.
- Operating altitude:
0.
- 2000 m Technical details:
- Sustainability certificates:
RoHS.
Weight & dimensions:
- Width:438 mm.
- Depth:632 mm.
- Height:88 mm.
- Weight:27.6 kg Packaging data:
- Package width:760 mm.
- Package depth:240 mm.
- Package height:600 mm.
- Package weight:31.2 kg.
